AirFit X30i

Stable and reliable sleep therapy

• The oral nasal design offers the coverage of a full face mask, and the stability and seal of a nasal pillows cushion.
• To help keep your mask in peak condition, both the oral and nasal pillow cushions may be replaced up to twice per month.*

Sleep the way you want

• The tube connects to the frame at the top of the head so that it’s out of the way, giving you the freedom to sleep in any position without compromising seal performance.
• With QuietAir™ diffused venting, you and your bed partner will enjoy a quiet night’s rest with less disturbances.

Easy to use and remove

• The quick-release elbow makes it easy to disconnect the mask from the tubing if you need to get up at night.
• The headgear has magnetic clips so you can put on and take off your mask in just two simple snaps.**

*Reimbursement for AirFit X30i is different than a full face mask. Timelines provided are U.S. Medicare replacement timeframes. Co-pays, deductibles and co-insurance may apply. U.S. Medicare’s allowable cushion replacement is one (1) per month for a full face mask. Because the AirFit X30i is an oral nasal mask, each of the oral and nasal pillows cushions may be replaced up to two (2) times per month. See below for the list of oral nasal HCPCS codes. For more information, refer to your Medicare local coverage determination policy, which you can find online at: https://www.cms.gov/medicare-coverage-database/

Oral nasal HCPCS codes:

• A7027 Combination oral/nasal mask
• A7028 Replacement oral cushion for combination oral/nasal mask
• A7029 Replacement nasal pillows for combination oral/nasal mask
• A7035 Headgear

Note: Other payer guidelines may vary. It is your responsibility to verify all reimbursement requirements.

The information is being provided on an “as is” basis with no express or implied warranty of any kind and should be used solely for your internal informational purposes only. The information does not constitute professional or legal advice on reimbursement and should be used at your sole liability and discretion. All coding, coverage policies and reimbursement information are subject to change without notice. Resmed does not represent or warrant that any of the information being provided is true or correct, and you agree to hold Resmed harmless in the event of any loss, damage, liabilities or claims arising from the use of the reimbursement information provided to you. Before filing any claims, it is the provider’s sole responsibility to verify current requirements and policies with the payer.

**The mask contains magnets that may interfere with certain implants or medical devices. Please refer to the User Guide for complete labeling information, including magnet contraindications and warnings.

Disassembly

If your mask is connected to a device, disconnect the device air tubing from the mask elbow.

Undo the fastening tabs on the upper headgear straps and pull from the frame. Keep the magnetic clips attached to the lower headgear straps.

Squeeze the side buttons on the elbow and detach from the frame.

Grip the frame connector and lift to unclip from the cushion. Repeat on the other side.

Pull the pillow from the oral cushion.

Assembly

Align and insert the frame connector tab (a) into the cushion slot (b) and press down until it clicks. Repeat on the other side.

Attach the elbow to the top of the frame until it clicks.

With the Resmed logo facing outwards and up, insert the upper headgear straps into the frame from the inside.

Fold the fastening tabs over to secure.

Place the pillow above the oral cushion, ensuring that the pillows tab (a) is aligned to the oral cushion slot (b)

Rotate the pillows forward and press into the oral cushion until it clicks.
